306-009-520-102 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FML 120POS 0.100. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 306-009-520-102
- Description：CONN EDGE DUAL FML 120POS 0.100
- Series：306
- Mfr：EDAC Inc.
- Package：Box
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：9
- Number of Positions：18
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：-
- Mounting Type：Panel Mount, Through Hole
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：10.0µin (0.25µm)
- Contact Type：Cantilever
- Color：Green
- Flange Feature：Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia
- Operating Temperature：-40°C ~ 105°C
Edgeboard Connectors datasheet and documents for 306-009-520-102
Edgeboard Connectors Overview
The EDAC Inc. 306-009-520-102 is a standard card edge connector designed for dual-edge board insertion. It features 18 positions with a 3.96 mm pitch and supports a maximum current rating of 5 A. The contacts are gold-plated copper alloy, housed in green thermoplastic polyester. This vertical panel-mount receptacle accommodates PCB thicknesses of 1.57 mm and offers an insulation resistance of 5 GOhms.
Edgeboard Connectors Feature Summary
- Dual-edge contact configuration for secure board retention
- Gold-plated copper alloy terminals for reliable conductivity
- Vertical panel mount orientation for space-efficient integration
Edgeboard Connectors Applications
- Industrial control system interconnects
- Telecommunications equipment backplanes
- Medical device circuit board connections
Edgeboard Connectors Procurement Notes
Verify the specific manufacturer part number against official EDAC documentation to ensure compatibility with design requirements. Confirm that the dual-edge specification matches the target PCB layout. Check regional availability as distribution may be restricted in certain areas. Ensure environmental ratings meet operational temperature expectations.
Edgeboard Connectors Selection Notes
Select this component when a dual-edge connection is required for 18-position applications. The 3.96 mm pitch distinguishes it from standard 2.54 mm connectors. Verify that the housing material and color specifications align with assembly standards. Confirm that the vertical mounting style fits within the enclosure constraints.
Edgeboard Connectors Part Context
This component belongs to the EDAC 306 series of standard card edge connectors. The series provides various position counts and pitch options for general-purpose electronic interconnects. The 306 series utilizes thermoplastic polyester housings and copper alloy contacts for durability.
Edgeboard Connectors Replacement Considerations
No public confirmed substitute part numbers are available in the provided data. Consult EDAC technical support for equivalent alternatives if this specific part number is unavailable.
