306-011-400-103

Edgeboard Connectors Overview

The EDAC Inc. model 306-011-400-103 is a dual female edgeboard connector featuring 22 positions with a contact spacing of 0.156 inches (3.96 mm). It utilizes a single central row configuration designed to accept printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm). The component incorporates a low-profile insulator body and is constructed from copper alloy contacts.

Edgeboard Connectors Feature Summary

• Single central row design for standard board insertion
• Low profile insulator body construction
• Copper alloy contact material

Edgeboard Connectors Applications

• Standard card edge interconnection systems
• Electronic modules requiring 0.062 inch board thickness
• Industrial control panel interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's current documentation to ensure compatibility with required mounting styles and termination types. Confirm that the 22-position count aligns with the target application requirements before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a single central row interface is required for 0.062 inch thick PCBs. Ensure the system design accommodates the 0.156 inch pitch and verify that the low-profile form factor meets the spatial constraints of the enclosure.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series, which provides various contact terminations and mounting options. The series includes multiple card guide solutions and high-temperature insulators to support diverse industrial and commercial electronic applications.

Edgeboard Connectors Replacement Considerations

Consult official EDAC substitution guides for verified alternative part numbers. Generic cross-references may not match the specific 0.156 inch pitch or 0.062 inch board thickness requirements.
