306-011-420-102

$6.81

Description：CONN EDGE DUAL FMALE 22POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk

SKU:fa256531be79 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

306-011-420-102 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 22POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 306-011-420-102

Description：CONN EDGE DUAL FMALE 22POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：11
Number of Positions：22
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Tin
Contact Finish Thickness：-
Contact Type：Cantilever
Color：Green
Flange Feature：Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 306-011-420-102

306-011-420-102

Edgeboard Connectors Overview

The EDAC Inc. 306-011-420-102 is a standard card edge connector from the 306 series, designed for dual female edgeboard applications. It features 11 positions with a contact spacing of 0.156 inches (3.96 mm). The component utilizes tin plating on its contacts and is constructed with a green insulator body. It accepts printed circuit boards with a nominal thickness of 0.062 inches (1.57 mm) and employs a single centerline row configuration.

Edgeboard Connectors Feature Summary

Dual female edge connector design for secure board retention
Single centerline row configuration with 0.156 inch spacing
Tin-plated contacts for reliable signal transmission
Low profile insulator body compatible with 0.062 inch PCBs

Edgeboard Connectors Applications

Industrial control panel interconnections
Telecommunications equipment backplanes
Test and measurement instrument modules

Edgeboard Connectors Procurement Notes

Verify the specific plating finish and material composition against the manufacturer's official datasheet prior to procurement. Confirm that the required PCB thickness aligns with the 0.062-inch specification. Ensure that the tin plating meets the environmental and durability requirements for the intended operational environment. Cross-reference the part number with authorized distributors to confirm current availability and authenticity.

Edgeboard Connectors Selection Notes

Select this component when a dual female card edge connector with 11 positions is required. The 0.156-inch pitch suits applications needing wider spacing for high-current or high-voltage isolation. The tin-plated contacts offer a cost-effective solution for general-purpose connections. Ensure the mounting style and panel cutout dimensions are compatible with the low-profile body design.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series, which provides standard card edge connectors with 0.156-inch contact spacing. The series offers various position counts and termination options. The 306-011-420-102 specifically addresses needs for dual-sided female connectors in compact industrial and commercial electronics assemblies.
