306-011-500-108

Edgeboard Connectors Overview

The EDAC 306-011-500-108 is a standard card edge connector receptacle featuring 11 positions with a 3.96 mm (0.156 inch) contact spacing. Designed for vertical panel mount installation, it accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inch). The component utilizes gold-plated copper alloy contacts and a thermoplastic polyester insulator body. It supports a current rating of 5 A and operates within a temperature range of -40°C to 105°C.

Edgeboard Connectors Feature Summary

• Accepts .062" (1.57mm) nominal thickness P.C. Board
• Low profile insulator body design
• Single centreline row configuration

Edgeboard Connectors Applications

• Card edge interconnect solutions
• Rack and panel applications
• Computing and storage systems
• Industrial control modules

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer datasheet to confirm flange features and mounting style. Ensure the selected variant matches the required board thickness and contact plating specifications for the target application environment.

Edgeboard Connectors Selection Notes

Select this component when a vertical, panel-mount card edge connector is required for 1.57 mm thick PCBs. The 11-position configuration suits applications needing moderate I/O density. Verify that the flush mount flange feature aligns with the chassis design requirements.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 Series, which provides standard card edge connectors with .156 inch contact spacing. The series offers various position counts and mounting styles for general-purpose interconnect needs in industrial and commercial electronics.

Edgeboard Connectors Replacement Considerations

Direct substitutes include other EDAC 306 series variants with matching 11 positions and 3.96 mm pitch, such as 306-011-500-101, provided flange configurations are compatible.
