306-011-520-178

Edgeboard Connectors Overview

The EDAC Inc. 306-011-520-178 is a standard card edge connector from the 306 Series, designed for through-hole mounting with a straight orientation. It features 11 positions and a contact spacing of 3.96 mm (0.156 inches). The connector accepts printed circuit boards with a nominal thickness of 1.57 mm (0.062 inches). Contacts are made of copper alloy with gold plating to ensure reliable signal transmission. The unit has a current rating of 5 A and utilizes a thermoplastic polyester insulator body.

Edgeboard Connectors Feature Summary

• Features a low-profile insulator body constructed from thermoplastic polyester.
• Utilizes tail-type contacts with gold plating on the contact area for durability.
• Designed to accept nominal 0.062-inch thick printed circuit boards.

Edgeboard Connectors Applications

• Communication equipment interconnections
• Industrial control system board connections
• Consumer electronic device assembly

Edgeboard Connectors Procurement Notes

Verify the specific part number against official EDAC documentation to confirm compatibility with your PCB design requirements. Ensure that the through-hole mounting style and straight orientation align with your assembly process. Confirm that the 5 A current rating and 3.96 mm pitch meet the electrical specifications of your application before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a single centerline row card edge connector is required for 0.062-inch thick boards. The 306 series offers a balance of low profile and robust mechanical connection. Consider the gold-plated copper alloy contacts for applications requiring corrosion resistance and stable conductivity over repeated mating cycles.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 Series, which provides standard card edge connectors with 0.156-inch contact spacing. The series includes various position counts and mounting styles to support diverse electronic assembly needs. EDAC specializes in high-quality connectors for communication, industrial, and consumer markets, ensuring reliable performance across different environmental conditions.

Edgeboard Connectors Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing designs if considering alternative suppliers or pin-compatible options from other manufacturers.
