306-013-420-178

Edgeboard Connectors Overview

The EDAC Inc. 306-013-420-178 is a standard card edge connector receptacle featuring 13 positions with a 3.96 mm pitch. Designed for through-hole mounting at a straight angle, it accepts printed circuit boards with a nominal thickness of 1.57 mm. The contacts are constructed from copper alloy and feature gold plating to ensure reliable signal transmission. Rated for 5 A current, the unit utilizes a thermoplastic polyester insulator body. This component belongs to the EDAC 306 series, providing a robust interface solution for single-row card edge applications.

Edgeboard Connectors Feature Summary

• Accepts nominal 1.57 mm thick printed circuit boards
• Gold-plated copper alloy contacts for conductivity
• Thermoplastic polyester insulator body

Edgeboard Connectors Applications

• Single-row card edge board connections
• Industrial control panel interfaces
• Communication equipment backplanes

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to confirm contact configuration and plating specifications. Ensure compatibility with the target PCB thickness of 1.57 mm and verify that the straight-mount style aligns with the assembly requirements. Cross-reference the 13-position count with the design layout before procurement.

Edgeboard Connectors Selection Notes

Select this component when a 3.96 mm pitch is required for single-row card edge applications. It is suitable for designs needing through-hole termination with a straight orientation. Consider the 5 A current rating and gold-plated contacts for durability. Verify that the thermoplastic polyester housing meets environmental constraints for the intended operating temperature range.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series, which specializes in standard card edge connectors with a 3.96 mm (0.156 inch) contact spacing. The series offers various position counts and mounting styles. The 306-013-420-178 specifically denotes a 13-position receptacle variant within this standardized family, designed for general-purpose electronic interconnections.

Edgeboard Connectors Replacement Considerations

Consult the official EDAC catalog for direct substitutes within the 306 series with different position counts or mounting angles. No public cross-reference data confirms equivalent parts from other manufacturers.
