306-013-521-107

Edgeboard Connectors Overview

The EDAC Inc. 306-013-521-107 is a standard card edge connector featuring 30 positions with a 3.96 mm pitch. It utilizes a single row of gold-plated copper alloy contacts housed in a thermoplastic body. Designed for panel mounting, this vertical connector accepts printed circuit boards with a nominal thickness of 1.57 mm. It supports a current rating of 5 A and operates within a temperature range of -40 C to +105 C, offering an insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

• Gold-plated copper alloy contacts ensure reliable signal transmission
• Thermoplastic insulator body provides structural stability
• Vertical panel mount configuration facilitates secure installation

Edgeboard Connectors Applications

• Industrial control systems requiring robust interconnects
• Communication equipment backplanes
• Medical device circuit board interfaces

Edgeboard Connectors Procurement Notes

Verify the specific contact count and pitch against project requirements before ordering. Confirm that the target PCB thickness matches the 1.57 mm specification to ensure proper mating. Check regional availability as distribution status may vary. Ensure compliance with RoHS directives if required by the end application. Cross-reference the datasheet for precise mechanical dimensions.

Edgeboard Connectors Selection Notes

Select this component when a single-row card edge interface with 3.96 mm spacing is required. The vertical orientation suits panel-mounted applications where space efficiency is critical. Consider the 5 A current rating for power distribution needs. Verify compatibility with the host system's thermal environment given the operating temperature limits.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of card edge connectors. The series is characterized by standardized spacing and durable construction suitable for various electronic assemblies. EDAC specializes in high-reliability interconnect solutions for industrial and commercial sectors.

Edgeboard Connectors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official EDAC resources or authorized distributors for compatible alternatives.
