306-014-520-178

$10.32

Description：CONN EDGE DUAL FMALE 28POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Box

SKU:452444a8eba8 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

306-014-520-178 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 28POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 306-014-520-178

Description：CONN EDGE DUAL FMALE 28POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：14
Number of Positions：28
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：Card Guides
Mounting Type：Panel Mount, Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Flush Mount, Top Opening, Threaded Insert, 4-40
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 306-014-520-178

306-014-520-178

Edgeboard Connectors Overview

The EDAC Inc. model 306-014-520-178 is a standard card edge connector receptacle featuring 28 positions with a 3.96 mm (0.156 inch) pitch. It utilizes gold-plated copper alloy contacts and a thermoplastic housing, rated for 5 A current. Designed for through-hole vertical mounting, it accommodates PCB thicknesses between 1.37 mm and 1.78 mm. The component includes flush mount flange features with top openings and threaded inserts for secure installation.

Edgeboard Connectors Feature Summary

Dual-edge female contact configuration for reliable signal transmission
Gold-plated contacts ensure corrosion resistance and low contact impedance
Flush mount flange design with threaded insert integration for structural stability

Edgeboard Connectors Applications

Industrial control system interconnections
Telecommunications equipment backplanes
Consumer electronics module interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix to confirm the exact flange configuration and termination style required for your assembly. Ensure compatibility with the target PCB stack-up dimensions before finalizing procurement orders. Cross-reference the manufacturer datasheet for precise mechanical tolerances to guarantee proper fit during integration.

Edgeboard Connectors Selection Notes

Select this component when a 28-position interface with a 3.96 mm pitch is required. Consider the 5 A current rating and thermoplastic housing material for general-purpose applications. Evaluate the through-hole vertical mounting style against available board space constraints.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series provides various position counts and mounting options for diverse electronic interconnection needs. The 306 series is widely utilized in industrial and commercial sectors requiring robust board-to-board connectivity solutions.
