306-015-520-102

$10.96

Description：CONN EDGE DUAL FMALE 30POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk

SKU:1f44b7f056aa Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

306-015-520-102 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 30POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 306-015-520-102

Description：CONN EDGE DUAL FMALE 30POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Bulk
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：15
Number of Positions：30
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Flush Mount, Top Opening, Unthreaded, 0.128" (3.25mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 306-015-520-102

306-015-520-102

Edgeboard Connectors Overview

The EDAC 306-015-520-102 is a standard card edge connector receptacle featuring 15 positions with a 3.96 mm pitch. It utilizes gold-plated copper alloy contacts and a thermoplastic polyester housing, rated for 5 A current and 5 GOhms insulation resistance. Designed for vertical panel mount installation, it accommodates a board thickness of 1.57 mm. The component operates within a temperature range up to +105°C and belongs to the 306 series.

Edgeboard Connectors Feature Summary

Vertical panel mount configuration for secure mechanical integration
Gold-plated copper alloy contacts ensuring reliable signal transmission
Thermoplastic polyester housing providing thermal stability

Edgeboard Connectors Applications

Industrial control systems requiring robust interconnects
Telecommunications equipment interfaces
Test and measurement instrumentation panels

Edgeboard Connectors Procurement Notes

Verify specific ordering suffixes against official EDAC documentation to ensure exact pin count, contact plating, and housing color match design requirements. Confirm RoHS compliance status and moisture sensitivity level prior to procurement. Cross-reference datasheet specifications with system constraints to validate electrical ratings and physical dimensions.

Edgeboard Connectors Selection Notes

Select this component when a 15-position vertical card edge interface with a 3.96 mm pitch is required. Ensure the mating PCB thickness aligns with the 1.9 mm specification. Consider the 5 A current rating and +105°C maximum operating temperature for environmental suitability. Verify that the dual-edge card type compatibility matches the application's circuit board design.

Edgeboard Connectors Part Context

This part belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and pitch options for diverse electronic applications. The 306-015-520-102 specifically addresses needs for medium-density vertical connections in industrial and commercial electronics environments.
