306-015-520-178

Edgeboard Connectors Overview

The EDAC Inc. part number 306-015-520-178 is a standard card edge connector receptacle designed for through-hole mounting. It features a dual female configuration with 30 positions arranged in two rows. The connector utilizes a 3.96 mm (0.156 inch) pitch and supports board thicknesses of 1.57 mm. Contacts are made of copper alloy with gold plating, rated for 5 A current. The housing is constructed from thermoplastic polyester, and the unit operates within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Dual female contact configuration for secure edgeboard insertion
• Gold-plated cantilever spring contacts ensure reliable electrical connection
• Thermoplastic polyester housing provides structural integrity and insulation
• Through-hole solder termination facilitates PCB integration

Edgeboard Connectors Applications

• Industrial control system interconnections
• Communication equipment backplanes
• Consumer electronics module interfaces
• Medical device circuit board connections

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against the manufacturer's official ordering guide to confirm pin count, contact finish, and flange options. Ensure compatibility with the target PCB thickness and mounting style requirements before procurement. Cross-reference the full part number with distributor catalogs to confirm availability status and lead times, as distribution channels may vary by region.

Edgeboard Connectors Selection Notes

Select this component when a dual-row, 30-position card edge interface is required with a 3.96 mm pitch. Confirm that the application environment falls within the specified -40°C to +105°C operating range. Verify that the PCB design accommodates the 1.57 mm board thickness constraint and that the through-hole mounting style aligns with the assembly process.

Edgeboard Connectors Part Context

This component belongs to the EDAC 306 series of standard card edge connectors. The series offers various position counts and mounting configurations. The 306-015-520-178 specifically denotes a 30-position dual female variant with gold contacts and thermoplastic housing, intended for general-purpose electronic interconnection applications requiring robust mechanical and electrical performance.

Edgeboard Connectors Replacement Considerations

Consult the EDAC 306 Series Ordering Guide for direct substitutes with differing position counts or contact finishes. Verify mechanical dimensions and electrical ratings before substituting with components from other manufacturers to ensure interface compatibility.
