Product Detailed Parameters
- Description：CONN EDGE DUAL FMALE 58POS 0.156
- Series：306
- Mfr：EDAC Inc.
- Package：Box
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：29
- Number of Positions：58
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：Card Guides
- Mounting Type：Panel Mount
- Termination：Solder Eyelet(s)
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：10.0µin (0.25µm)
- Contact Type：Cantilever
- Color：Green
- Flange Feature：Flush Mount, Top Opening, Threaded Insert, 4-40
- Operating Temperature：-40°C ~ 105°C
Download product information
Overview
The EDAC Inc. 306-029-500-178 is a standard card edge connector receptacle from the 306 series. It features 29 positions with a 3.96 mm (0.156 inch) pitch and accepts printed circuit boards with a nominal thickness of 1.57 mm. The connector utilizes gold-plated copper alloy contacts for reliable signal transmission and is designed for through-hole solder termination. Constructed with a thermoplastic polyester insulator, it supports panel mounting in a straight orientation. The component is rated for 5 A current and operates within a temperature range of -40°C to +105°C.
Feature Summary
- Accepts single-sided PCBs with a nominal thickness of 1.57 mm
- Features low-profile insulator body design
- Utilizes gold-plated copper alloy contacts for durability
Applications
- Industrial control systems
- Telecommunications equipment
- Consumer electronics assemblies
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct contact spacing and board thickness compatibility. Confirm that the required position count matches the 29-position specification. Check RoHS compliance status directly with the supplier documentation prior to procurement to meet regulatory requirements.
Selection Notes
Select this component when a single-row card edge interface with a 3.96 mm pitch is required. Ensure the target PCB thickness aligns with the 1.57 mm nominal specification. Consider the 5 A current rating and operating temperature range for environmental suitability. Verify that the straight through-hole mounting style fits the mechanical constraints of the enclosure design.
Part Context
This part belongs to the EDAC 306 series of standard card edge connectors. The series is characterized by a 3.96 mm contact spacing and a low-profile insulator body. These connectors are designed for general-purpose applications requiring reliable interconnection between a housing and a single-sided printed circuit board.
Replacement Considerations
Consult the EDAC 306 Series Ordering Guide for verified substitute part numbers. Cross-reference position counts and pitch specifications to ensure mechanical and electrical compatibility before substitution.
