Product Detailed Parameters
- Description：CONN EDGE DUAL FMALE 60POS 0.156
- Series：306
- Mfr：EDAC Inc.
- Package：Bulk
- Card Type：Non Specified - Dual Edge
- Gender：Female
- Number of Positions/Bay/Row：30
- Number of Positions：60
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：2
- Pitch：0.156" (3.96mm)
- Read Out：Dual
- Features：Card Guides
- Mounting Type：Panel Mount, Through Hole
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Tin
- Contact Finish Thickness：-
- Contact Type：Cantilever
- Color：Green
- Flange Feature：Flush Mount, Top Opening, Threaded Insert, 4-40
- Operating Temperature：-40°C ~ 105°C
Download product information
Overview
The EDAC Inc. model 306-030-421-168 is a standard card edge connector from the 306 series, designed for vertical panel mounting applications. It features a single row of 60 female contacts with a 3.96 mm (0.156 inch) pitch. The connector utilizes tin-plated copper alloy terminals and accepts printed circuit boards with a nominal thickness of 1.57 mm. Constructed with a green thermoplastic insulator body, it supports solder termination and operates within a temperature range of -40°C to +105°C.
Feature Summary
- Vertical panel mount design with single centerline row configuration
- Accepts non-specified dual-edge PCBs with nominal 1.57 mm thickness
- Tin-plated copper alloy contacts for reliable signal transmission
Applications
- Industrial control systems requiring robust board-to-board connections
- Medical interconnect solutions demanding durable contact interfaces
- Agricultural technology equipment needing reliable electronic integration
Procurement Notes
Verify the specific ordering suffix against the manufacturer's official datasheet to ensure correct contact plating and insulation material specifications. Confirm that the required PCB thickness aligns with the connector's acceptance range. Check current product status as availability may vary by region or distributor channel.
Selection Notes
Select this component when a vertical, single-row interface is required for thicker PCBs up to 1.57 mm. Ensure the application environment remains within the specified operating temperature limits. Verify that the tin plating meets the corrosion resistance requirements for the intended operational conditions.
Part Context
This part belongs to the EDAC 306 series, which provides standard card edge connectors for various industrial and commercial applications. The series offers multiple positioning options and mounting styles, supporting diverse electronic assembly needs across communication, consumer electronics, and energy sectors.
Replacement Considerations
Consult the official EDAC 306 Series Ordering Guide for compatible alternatives. Verify pin count, pitch, and mounting style compatibility before substituting.
