306-031-500-101

$14.00

Description：CONN EDGE DUAL FMALE 62POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Box

SKU:39362fe1a06f Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN EDGE DUAL FMALE 62POS 0.156
Series：306
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：31
Number of Positions：62
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Free Hanging (In-Line)
Termination：Solder Eyelet(s)
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：-
Operating Temperature：-40°C ~ 105°C

Download product information

306-031-500-101

Overview

The EDAC Inc. part number 306-031-500-101 is a standard card edge connector belonging to the 306 series. It features a dual female configuration with 62 positions arranged in a single centerline row. The connector utilizes a .156 inch (3.96mm) contact spacing and is designed to accept printed circuit boards with a nominal thickness of .062 inches (1.57mm). Key electrical specifications include a current rating of 5 A, an insulation resistance of 5 GOhms, and an operating temperature range from -40°C to +105°C. The housing is constructed from thermoplastic material.

Feature Summary

Dual female contact configuration for secure board insertion
Low profile insulator body design
Solder eyelet termination method for reliable PCB mounting

Applications

Standard card edge interconnections
Industrial control systems
Communication equipment backplanes

Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct contact finish and termination style. Confirm that the required quantity aligns with the factory pack quantity of 25 units per package. Cross-reference the datasheet version to validate compliance with current industry standards before finalizing procurement orders.

Selection Notes

Select this component when a dual female card edge connector with 62 positions is required. Ensure the target PCB thickness matches the .062 inch specification. Verify that the thermal environment stays within the -40°C to +105°C operational limits. Confirm compatibility with the .156 inch contact spacing requirement for the system design.

Part Context

This connector is part of EDAC's extensive portfolio of high-quality interconnection solutions. The 306 series represents standard card edge connectors suitable for various applications including consumer electronics, medical devices, and industrial sectors. EDAC provides comprehensive product manuals and 3D models to support integration into broader system architectures.

Replacement Considerations

Consult official substitution lists for verified equivalent part numbers. Generic cross-references may not match critical parameters such as contact spacing or termination style. Validate any alternative components against the original datasheet specifications to ensure functional compatibility.
