306-035-500-108

Overview

The EDAC Inc. 306-035-500-108 is a dual female edgeboard connector designed for high-density signal transmission. It features 70 positions arranged in a single centerline row with a contact spacing of 0.156 inches (3.96mm). The unit accepts printed circuit boards with a nominal thickness of 0.062 inches (1.57mm). Constructed with a low-profile polyester thermoplastic insulator body, it provides reliable mechanical stability and electrical continuity for vertical mating applications.

Feature Summary

• Dual female configuration supporting simultaneous board insertion
• Single centerline row design for compact layout integration
• Low-profile insulator body for space-constrained environments

Applications

• Industrial control system backplanes
• Telecommunications equipment interconnects
• Medical device internal module connections

Procurement Notes

Verify the specific ordering suffix to confirm pin count and flange configuration match the design requirements. Ensure compatibility with the target PCB thickness of 0.062 inches. Confirm that the supplier provides official datasheets for the exact part number variant to validate material specifications and termination types before finalizing procurement orders.

Selection Notes

Select this component when a dual-sided connection is required within a single-row footprint. The 0.156-inch pitch offers a balance between density and manufacturability. Consider the flush mount flange feature if panel mounting stability is necessary. Evaluate thermal performance requirements against the standard operating temperature range specified in the manufacturer documentation.

Part Context

This connector belongs to the EDAC 306 series, which specializes in edgeboard connectors for modular systems. The series is characterized by its robust construction and standardized dimensions, facilitating interchangeability across various industrial and commercial electronic assemblies. It represents a standard solution for reliable card-edge interfacing.

Replacement Considerations

Cross-reference with other EDAC 306 series variants such as 306-035-500-107 for different pin counts. Verify that substitute parts maintain the same 0.156-inch spacing and dual female gender to ensure mechanical fit without redesigning the host PCB or chassis.
