307-014-501-101

Edgeboard Connectors Overview

The EDAC Inc. 307-014-501-101 is a standard card edge connector from the 307 series, designed for dual-edge board applications. It features 28 positions with a 3.96 mm (0.156 inch) pitch and accommodates a board thickness of 1.57 mm. The connector utilizes gold-plated copper alloy contacts and a green thermoplastic insulator. Rated for 5 A current, it supports vertical panel mounting without lugs. Operating temperatures range from -40°C to +105°C, with an insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

• Dual-edge female contact configuration for secure board insertion
• Gold-plated copper alloy contacts ensure reliable conductivity
• Thermoplastic housing provides structural stability and insulation

Edgeboard Connectors Applications

• Panel-mounted electronic assemblies requiring dual-edge connectivity
• Industrial control systems utilizing standard card edge interfaces
• Test and measurement equipment needing robust signal connections

Edgeboard Connectors Procurement Notes

Verify the specific pin count and orientation against project requirements, as datasheets may list conflicting position counts. Confirm that the dual-edge design aligns with the target PCB layout. Ensure the operating temperature range meets environmental specifications. Cross-reference the manufacturer part number with authorized distributors to confirm authenticity and availability status before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this component when a dual-edge interface is required rather than single-sided alternatives. The 3.96 mm pitch dictates compatible PCB trace spacing. Verify that the panel mounting style fits the enclosure constraints. Consider the 5 A current rating for power distribution needs. Ensure the thermoplastic material compatibility matches thermal management requirements.

Edgeboard Connectors Part Context

This part belongs to the EDAC 307 series of standard card edge connectors. The series offers various configurations including single and dual-edge options with different position counts. The 307 series is characterized by its use of thermoplastic housings and standardized 3.96 mm pitch dimensions, providing a versatile solution for general-purpose interconnect applications in industrial and commercial electronics.

Edgeboard Connectors Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify mechanical fit and electrical parameters before considering alternative manufacturers. Consult official EDAC catalogs for direct cross-references within the same series.
