310-44-132-41-001000

Headers, Receptacles, Female Sockets Overview

The Mill-Max 310-44-132-41-001000 is an IC and component socket designed for through-hole mounting. It features a 32-position configuration arranged in a dual-in-line package (DIP) with a 0.6-inch row spacing. The connector utilizes wire-wrap termination methods and includes gold-plated contacts to ensure reliable signal transmission. Constructed with a PCT polyester housing, it supports a wide operating temperature range from -55°C to 125°C. This component is part of the 310 series, offering high reliability for precision interconnect applications requiring durable mechanical and electrical performance.

Headers, Receptacles, Female Sockets Feature Summary

• Features a 32-position DIP socket design with 0.6-inch row spacing for standard IC integration.
• Utilizes wire-wrap termination technology for secure PCB connection without soldering.
• Incorporates gold-plated contacts on copper alloy bases to minimize contact resistance and prevent corrosion.
• Constructed with PCT polyester insulation material rated for UL94 V-0 flammability.

Headers, Receptacles, Female Sockets Applications

• Through-hole mounting for integrated circuit sockets
• Precision-machined interconnect components
• High-reliability electronic assembly

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and termination style against official datasheets before procurement. Confirm RoHS compliance status and environmental certifications required for your region. Ensure the wire-wrap tooling matches the contact specifications. Check for any obsolescence notices or lifecycle changes directly from the manufacturer. Validate that the 0.6-inch row spacing aligns with your PCB footprint requirements.

Headers, Receptacles, Female Sockets Selection Notes

Select this model when wire-wrap termination is preferred over soldering for serviceability. Choose based on the need for a 32-position DIP configuration with extended row spacing. Consider the gold plating thickness for long-term durability in harsh environments. Verify thermal rating compatibility with your operational temperature extremes. Ensure the open-frame design fits within your enclosure constraints.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Mill-Max 310 series of IC sockets. It is manufactured by Mill-Max Manufacturing Corp., a provider of high-reliability interconnect solutions. The product is categorized under IC and component sockets, specifically designed for through-hole applications. It serves as a critical interface between printed circuit boards and integrated circuits.

Headers, Receptacles, Female Sockets Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Consult the manufacturer's catalog for cross-reference options if this specific model is unavailable.
