310-83-130-41-205101

$3.98

Description：CONN SOCKET 30P 0.1 GOLD SMD R/A
Series：310
Mfr：Preci-Dip
Package：Bulk

SKU:238b5049a7aa Category: Headers, Receptacles, Female Sockets Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

310-83-130-41-205101 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN SOCKET 30P 0.1 GOLD SMD R/A. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for 310-83-130-41-205101

Description：CONN SOCKET 30P 0.1 GOLD SMD R/A
Series：310
Mfr：Preci-Dip
Package：Bulk
Connector Type：Socket
Contact Type：Female Socket
Style：Board to Board
Number of Positions：30
Number of Positions Loaded：All
Pitch - Mating：0.100" (2.54mm)
Number of Rows：1
Row Spacing - Mating：-
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Insulation Color：Black
Insulation Height：0.100" (2.54mm)
Contact Length - Post：-
Operating Temperature：-55°C ~ 125°C
Material Flammability Rating：UL94 V-0
Contact Finish - Post：Tin
Mated Stacking Heights：-
Ingress Protection：-
Features：-
Current Rating (Amps)：3A
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for 310-83-130-41-205101

310-83-130-41-205101

Headers, Receptacles, Female Sockets Overview

The Preci-Dip 310-83-130-41-205101 is a 30-position socket connector designed for surface mount applications. It features a right-angle orientation with a 0.100" (2.54mm) mating spacing. The contacts are gold-plated with a thickness of 0.75µm, while the posts are tin-plated. Constructed from PCT insulation, it supports a working temperature range of -55°C to 125°C and carries UL94 V-0 flammability ratings.

Headers, Receptacles, Female Sockets Feature Summary

Right-angle surface mount geometry for compact board integration
Gold-plated mating contacts ensuring reliable signal transmission
Tin-plated posts optimized for soldering processes

Headers, Receptacles, Female Sockets Applications

Board-to-board interconnections
Surface mount electronic assemblies
High-density circuit board layouts

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and contact plating specifications against project requirements before procurement. Confirm that the right-angle surface mount form factor aligns with the mechanical constraints of the target assembly. Ensure compatibility with standard reflow soldering profiles for tin-plated posts.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, right-angle socket is required for surface mounting. The gold plating on mating surfaces makes it suitable for applications demanding high reliability and corrosion resistance. Consider the 2.54mm pitch for standard component spacing compatibility.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 310 series, which specializes in right-angle socket connectors. The series is characterized by its surface mount capability and robust construction using glass-filled polyester insulation. It serves as a counterpart to header connectors within the same product family.
