Headers, Receptacles, Female Sockets Overview

Preci-Dip part number 310-87-124-01-754101 is a single-row SIL socket connector with 24 positions and a 2.54 mm (0.100 inch) pitch. It features straight, right-angle solder tails for through-hole mounting on printed circuit boards. The contacts are made of brass with tin plating on the mating interface and flash gold on the tail. Rated for 3A current at 100V AC or 150V DC, it operates within a temperature range of -55°C to 125°C. The housing is constructed from glass-filled PCT polyester, rated UL94 V-0.

Headers, Receptacles, Female Sockets Feature Summary

• Single-row socket configuration with clinched solder tails for reliable PCB attachment
• Dual-plated contact system combining tin for mating surfaces and flash gold for solder tails
• High-temperature resistant insulation material ensuring stability across extreme thermal conditions

Headers, Receptacles, Female Sockets Applications

• Industrial control panel interconnections
• Consumer electronics assembly
• Telecommunications equipment wiring

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against official Preci-Dip documentation to confirm exact plating thickness and tail geometry. Ensure compatibility with mating header dimensions before procurement. Confirm that the supplier provides genuine manufacturer parts to avoid counterfeit components affecting electrical reliability.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a single-row, 24-position connection is required with a standard 2.54 mm spacing. It is suitable for applications needing robust through-hole termination without the need for additional securing hardware. Consider the operating voltage and current ratings relative to the circuit load requirements.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Preci-Dip 310 series of single-in-line sockets. These connectors are designed for general-purpose board-to-board or wire-to-board connections. The series offers various pin counts and plating options to suit different environmental and electrical demands in electronic assemblies.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other 24-position, 2.54mm pitch SIL sockets with similar solder tail configurations. Verify mechanical footprint and pinout alignment before swapping. Generic equivalents may lack the specific dual-plating characteristics of the original part.
