Headers, Receptacles, Female Sockets Overview

The Preci-Dip 310-87-146-41-105101 is a surface-mount IC DIP socket featuring 10 positions arranged in a 2x5 grid. It utilizes a 0.100-inch (2.54mm) mating pitch and a 0.3-inch (7.62mm) row spacing. The connector employs gold-plated beryllium copper contacts for the mating interface and tin-plated brass posts for termination. Designed for through-hole soldering, it operates within a temperature range of -55°C to 125°C with a rated current of 1A.

Headers, Receptacles, Female Sockets Feature Summary

• Open-frame construction facilitates automated component insertion and visual inspection during assembly processes.
• Gold-plated contact surfaces ensure reliable electrical conductivity and resistance to corrosion over extended service life.
• Surface-mount design allows for direct integration onto printed circuit boards using standard reflow soldering techniques.

Headers, Receptacles, Female Sockets Applications

• Socketing integrated circuits in surface-mounted electronic assemblies
• Prototyping and testing of DIP packaged components on custom PCBs
• Replacement sockets for field repair of DIP-based hardware

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific ordering suffix matches the required termination style and contact plating thickness. Confirm RoHS compliance status and moisture sensitivity level requirements against project specifications. Ensure the selected variant aligns with the intended surface-mount process parameters and thermal profile constraints.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, surface-mount solution is required for 10-position DIP packages. Consider the open-frame design for ease of access during maintenance. Evaluate the 1A current rating and 125°C maximum operating temperature against the application's electrical and thermal loads to ensure long-term reliability.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Preci-Dip 310 series of rectangular connectors. It is specifically engineered as an IC DIP socket variant designed for surface-mount technology. The product line offers various pin counts and configurations to support diverse integration needs in modern electronics manufacturing.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other 10-position surface-mount DIP sockets from Preci-Dip or compatible manufacturers offering identical 0.100-inch pitch and 0.3-inch row spacing. Verify mechanical footprint compatibility and terminal configuration before substitution.
