310-93-103-41-105000

Headers, Receptacles, Female Sockets Overview

The Mill-Max 310-93-103-41-105000 is a precision-machined IC socket designed for surface mount applications. It features a 3-position configuration with a 0.100-inch (2.54mm) contact spacing. The component utilizes gold-plated contacts to ensure reliable signal transmission and low contact resistance. Rated for 100 VRMS, it supports a current rating of 3 Amps per contact. The socket accepts pin diameters ranging from 0.015 to 0.025 inches, providing secure mechanical retention for integrated circuits in high-reliability electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount construction for automated PCB assembly
• Gold-plated contacts for enhanced conductivity and corrosion resistance
• Precision-machined design ensuring stable mechanical retention
• Compatible with standard IC pin dimensions

Headers, Receptacles, Female Sockets Applications

• Surface mount integration of small outline integrated circuits
• High-reliability electronic system interconnects
• Prototyping and testing sockets for SMD components
• Automated manufacturing processes requiring precise alignment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against the official Mill-Max datasheet to confirm exact plating thickness and tail diameter specifications. Ensure compatibility with the target PCB pad layout and reflow soldering profile. Confirm that the selected variant meets the required insulation resistance and dielectric withstand voltage standards for the intended operational environment.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when surface mount mounting is required for 3-pin ICs. Verify that the board space accommodates the socket footprint and that the operating voltage does not exceed 100 VRMS. Consider the 3 Amp current rating for power distribution needs. Ensure the IC pins fall within the 0.015 to 0.025 inch acceptance range for proper fit.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Mill-Max 310 series of machined pin sockets. These components are engineered for high-cycle durability and consistent electrical performance. The series offers various position counts and mounting options to support diverse integrated circuit packaging requirements in modern electronics manufacturing.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct substitutes include other Mill-Max 310 series sockets with matching 3-position configurations and surface mount footprints. Cross-reference the specific body height and terminal geometry to ensure mechanical compatibility with existing PCB designs.
