325-025-520-107

Edgeboard Connectors Overview

The EDAC Inc. 325-025-520-107 is a single-row card edge connector designed for standard board-to-board applications. It features 25 positions with a pitch of 2.54 mm (0.100 inch). The component utilizes a single female contact configuration suitable for connecting printed circuit boards. This connector belongs to the 325 series, which provides reliable electrical connections in various electronic assemblies.

Edgeboard Connectors Feature Summary

• Single row card edge connector design
• Standard 2.54 mm pitch spacing
• Female contact termination type

Edgeboard Connectors Applications

• General purpose electronic assemblies
• Board-to-board interconnections
• Industrial control systems

Edgeboard Connectors Procurement Notes

Verify the complete part number including suffixes when ordering. Confirm that the specific variant matches the required pin count and pitch specifications. Ensure compatibility with existing PCB layouts and mounting requirements before procurement.

Edgeboard Connectors Selection Notes

Select this connector based on the requirement for a single-row interface with 25 contacts. Consider the 2.54 mm pitch as a standard dimension for compatibility with common PCB designs. Evaluate mechanical stability needs against the single-row configuration limitations.

Edgeboard Connectors Part Context

This component is part of the EDAC 325 series, which offers various configurations for card edge applications. The series includes options with different row counts, pin numbers, and termination styles to suit diverse electronic design requirements.

Edgeboard Connectors Replacement Considerations

Direct substitutes within the same series include variants like 325-025-520-101 or other suffixes indicating different material or plating options. Verify exact dimensional and electrical equivalence before substitution.
