3250HV800-R

3250HV800-R is listed in the Fuses range at ChipApex. The manufacturer field lists Eaton - Electronics Division. Its product description is FUSE FAST ACT 0.8 A 1000 VDC SMD. Review the specifications below when checking this part for your BOM.

Fuses specifications for 3250HV800-R

• Description：FUSE FAST ACT 0.8 A 1000 VDC SMD
• Series：3250HV
• Mfr：Eaton - Electronics Division
• Package：Tape & Reel (TR),Cut Tape (CT)
• Mounting Type：Surface Mount
• Fuse Type：Board Mount (Cartridge Style Excluded)
• Current Rating (Amps)：800 mA
• Voltage Rating - DC：1 kV
• Response Time：Fast Blow
• Package / Case：2-SMD, Square End Block
• Breaking Capacity @ Rated Voltage：10kA
• Melting I²t：0.57
• Approval Agency：cURus
• Operating Temperature：-40°C ~ 125°C
• Color：-
• Size / Dimension：1.268" L x 0.198" W x 0.198" H (32.20mm x 5.03mm x 5.03mm)
• Voltage Rating - AC：-

Fuses datasheet and documents for 3250HV800-R
