333-014-524-203

$5.67

Description：CONN EDGE DUAL FMALE 14POS 0.156
Series：333
Mfr：EDAC Inc.
Package：Box

SKU:4ee2e87d1a06 Category: Edgeboard Connectors Brand: EDAC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

333-014-524-203 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE DUAL FMALE 14POS 0.156. Review the specifications below when checking this part for your BOM.

Edgeboard Connectors specifications for 333-014-524-203

Description：CONN EDGE DUAL FMALE 14POS 0.156
Series：333
Mfr：EDAC Inc.
Package：Box
Card Type：Non Specified - Dual Edge
Gender：Female
Number of Positions/Bay/Row：7
Number of Positions：14
Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
Number of Rows：2
Pitch：0.156" (3.96mm)
Read Out：Dual
Features：-
Mounting Type：Through Hole
Termination：Solder
Contact Material：Copper Alloy
Contact Finish：Gold
Contact Finish Thickness：10.0µin (0.25µm)
Contact Type：Cantilever
Color：Green
Flange Feature：Flush Mount, Floating Bobbin, 0.116" (2.95mm) Dia
Operating Temperature：-40°C ~ 105°C

Edgeboard Connectors datasheet and documents for 333-014-524-203

333-014-524-203

Edgeboard Connectors Overview

The EDAC Inc. 333-014-524-203 is a standard card edge connector featuring 14 positions with a 3.96 mm pitch. Designed for through-hole vertical mounting, it utilizes gold-plated copper alloy contacts and a thermoplastic polyester housing. The component supports a current rating of 3 A and an insulation resistance of 5 GOhms. It accommodates a board thickness of 1.57 mm and operates within a temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

Dual-side contact configuration for reliable signal transmission
Gold-plated terminals ensure corrosion resistance and stable conductivity
Vertical through-hole installation facilitates PCB integration

Edgeboard Connectors Applications

Industrial control systems requiring robust interconnects
Communication equipment interface modules
Consumer electronics internal board connections

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to confirm exact pin count, plating thickness, and flange specifications. Ensure compatibility with target PCB stack-up dimensions and thermal requirements before finalizing procurement orders.

Edgeboard Connectors Selection Notes

Select this model when a dual-edge, 14-position connector with a 3.96 mm pitch is required. Confirm that the application environment stays within the specified -40°C to +105°C operating range and that the PCB thickness matches the 1.57 mm design parameter.

Edgeboard Connectors Part Context

This component belongs to the EDAC 333 series of standard card edge connectors. The series offers various position counts and mounting styles, providing standardized solutions for board-to-board or backplane connections in electronic assemblies.
