337AXZ035M
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：ELECTROLYTIC/IC
- Series：AXZ
- Mfr：Cornell Dubilier Knowles
- Package：Tape & Reel (TR)
- Capacitance：330 µF
- Tolerance：±20%
- Voltage - Rated：35 V
- ESR (Equivalent Series Resistance)：703mOhm @ 120Hz
- Lifetime @ Temp.：2000 Hrs @ 105°C
- Operating Temperature：-55°C ~ 105°C
- Polarization：Polar
- Ratings：-
- Applications：Bypass, Decoupling
- Ripple Current @ Low Frequency：425 mA @ 120 Hz
- Ripple Current @ High Frequency：850 mA @ 100 kHz
- Lead Spacing：-
- Size / Dimension：0.394" Dia (10.00mm)
- Height - Seated (Max)：0.425" (10.80mm)
- Surface Mount Land Size：0.394" L x 0.394" W (10.00mm x 10.00mm)
- Mounting Type：Surface Mount
- Package / Case：Radial, Can - SMD
- Impedance：90 mOhms
