342-036-559-104

Edgeboard Connectors Overview

The EDAC Inc. model 342-036-559-104 is a standard card edge connector featuring 36 positions with a 2.54 mm pitch. It utilizes a single row configuration designed for through-hole mounting at a right angle. The connector supports a maximum board thickness of 1.57 mm and employs gold-plated copper alloy contacts to ensure reliable signal transmission. Rated for 3 A current, it operates within a temperature range of -40 °C to +105 °C. The housing is constructed from green thermoplastic polyester, providing structural integrity and insulation resistance of 5 GOhms.

Edgeboard Connectors Feature Summary

• Single-row female contact configuration for standard card edge mating
• Right-angle through-hole termination compatible with wire wrap processes
• Gold-plated copper alloy contacts ensuring low contact resistance
• Thermoplastic polyester insulator rated for high operating temperatures

Edgeboard Connectors Applications

• Industrial control system backplanes
• Telecommunications equipment interconnects
• Test and measurement instrument modules
• Embedded computing hardware interfaces

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm terminal type and plating specifications. Ensure compatibility with the target PCB panel thickness of 1.57 mm before integration. Confirm that the right-angle orientation aligns with the mechanical layout requirements of the assembly. Cross-reference the RoHS compliance status with current regulatory standards for the intended market.

Edgeboard Connectors Selection Notes

Select this component when a single-row, right-angle connection is required for 36-position boards. The 2.54 mm pitch suits standard digital logic applications. Consider the 3 A current rating for power distribution needs. The through-hole wire wrap termination offers robust mechanical stability compared to surface mount alternatives. Evaluate thermal constraints against the +105 °C maximum operating limit.

Edgeboard Connectors Part Context

This part belongs to the EDAC 342 series of standard card edge connectors. The series provides various position counts and mounting styles for diverse electronic assemblies. The 342-036-559-104 variant specifically addresses high-density single-row interface needs. It complements other EDAC products by offering reliable connectivity in compact form factors.

Edgeboard Connectors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify mechanical dimensions and electrical ratings against potential alternatives to ensure functional equivalence without modifying the existing design.

Edgeboard Connectors FAQ

What is the maximum operating temperature for this connector?

The maximum operating temperature is +105 °C.

Does this connector support double-sided card edges?

No, this is a single-row connector designed for single-sided card edge mating.
