Headers, Male Pins Overview

The Preci-Dip 350-10-134-00-106101 is a single-row male header connector designed for surface mount technology (SMT) applications. It features 34 positions with a 0.100-inch (2.54mm) pitch, suitable for board-to-board interconnections. The contacts are constructed from brass and finished with tin plating on both the mating interface and the tail for reliable soldering. Rated for 3A current and 150V DC, it utilizes PCT insulation material classified as UL94 V-0 for flame resistance. The connector supports a wide operating temperature range of -55°C to 125°C and employs a push-pull locking mechanism to ensure secure mating stability.

Headers, Male Pins Feature Summary

• Surface mount design for automated PCB assembly processes
• Tin-plated brass contacts for corrosion resistance and conductivity
• Push-pull locking system for secure mechanical retention
• High-temperature resistant PCT insulation housing

Headers, Male Pins Applications

• Board-to-board interconnects in industrial control systems
• Signal routing in consumer electronics assemblies
• Connection points in automotive electronic modules
• Interface links in telecommunications equipment

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required SMT footprint and pin count before procurement. Confirm that the tin-plated contact finish aligns with your soldering process requirements. Ensure compatibility with the mating female socket series within the same product family. Check that the voltage and current ratings meet the circuit specifications. Validate that the component complies with relevant environmental certifications such as RoHS if applicable to your manufacturing standards.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount male header is required for high-density connections. The 2.54mm pitch offers standard spacing compatibility with widespread industry connectors. Consider the push-pull feature if vibration resistance is critical for the application. The tin plating provides a balance between cost-effectiveness and performance for general-purpose signal applications. Ensure the PCB layout accommodates the specific SMT pad configuration defined by the manufacturer.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 350 series, which specializes in surface mount headers. The series is characterized by its compact profile and robust construction using glass-reinforced polyester insulation. It is designed to complement the company's socket counterparts, ensuring consistent electrical performance across mating pairs. The 350 series is widely used in applications requiring reliable, space-efficient interconnect solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes must maintain the 34-position count, 2.54mm pitch, and SMT mounting style. Verify that any alternative part uses compatible tin-plated brass contacts and similar insulation materials. Ensure the replacement supports the same 3A/150V rating and operating temperature range. Cross-reference the mechanical dimensions to guarantee PCB footprint compatibility.
