350-10-147-01-899101

$6.50

Description：CONN HEADER SMD 47POS 2.54MM
Series：350
Mfr：Preci-Dip
Package：Bulk

SKU:1d513bcdcdc7 Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

350-10-147-01-899101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER SMD 47POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 350-10-147-01-899101

Description：CONN HEADER SMD 47POS 2.54MM
Series：350
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：47
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.141" (3.60mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：Gold
Contact Material：Brass
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 350-10-147-01-899101

350-10-147-01-899101

Headers, Male Pins Overview

The Preci-Dip 350-10-147-01-899101 is a single-row board-to-board header connector designed for surface-mount technology. It features 47 positions with a 2.54mm (0.100 inch) pitch and utilizes gold-plated contacts on both the mating interface and the column termination points. The housing is constructed from black, glass-reinforced PCT polyester, rated UL94 V-0 for flammability. Electrical ratings include 150VDC and 3A current capacity. The connector employs push-pull retention mechanisms and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

Surface-mount design with push-pull locking mechanism for secure board attachment
Gold-plated brass contacts ensuring reliable signal transmission
High-temperature resistant PCT insulation material

Headers, Male Pins Applications

Board-to-board interconnections in electronic assemblies
Industrial control systems requiring robust connectivity
Consumer electronics utilizing surface-mount headers

Headers, Male Pins Procurement Notes

Verify the specific pin count and contact plating against the official datasheet before procurement. Confirm that the surface-mount footprint matches the target PCB layout. Ensure compatibility with reflow soldering profiles specified by the manufacturer. Check for RoHS compliance status if required by project regulations.

Headers, Male Pins Selection Notes

Select this component when a high-density, single-row header is required for surface mounting. The 2.54mm pitch is standard for general-purpose interconnects. Consider the push-pull feature if vibration resistance is critical. Verify that the 150VDC rating meets the circuit requirements.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 350 series, which offers various configurations of board-to-board connectors. The series includes options with different pin counts, plating types, and mounting styles. The 350-10 variant specifically denotes a single-row header with gold plating and surface-mount termination.
