350-80-117-00-206101

Headers, Male Pins Overview

The Preci-Dip 350-80-117-00-206101 is a rectangular header connector designed for surface mount applications. It features a right-angle configuration with 17 positions and a 0.100 inch (2.54mm) pitch. The contacts are male pins made of brass, finished with tin plating on both the mating and tail sections. Constructed from black PCT insulation rated UL94 V-0, it supports a maximum current of 3A and voltage of 150VDC across an operating temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Right-angle surface mount design facilitates compact PCB layout integration
• Tin-plated brass contacts ensure reliable electrical conductivity
• High-temperature resistant PCT insulation provides mechanical stability

Headers, Male Pins Applications

• Industrial control systems requiring robust interconnects
• Consumer electronics utilizing space-saving surface mount technology
• General-purpose board-to-board signal transmission

Headers, Male Pins Procurement Notes

Verify the specific pin count and orientation against your PCB footprint requirements before ordering. Confirm that the surface mount package type matches your assembly process capabilities. Ensure compatibility with mating female socket connectors within the same series to maintain proper engagement and electrical performance standards.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is necessary for limited vertical space constraints. Consider the 3A current rating and 150VDC voltage limit to ensure they meet circuit demands. Evaluate the thermal resistance provided by the PCT material if the application involves significant heat generation during operation.

Headers, Male Pins Part Context

This part belongs to the Preci-Dip 350 series, which specializes in rectangular headers and wire housings. The series offers various configurations including different pin counts and mounting styles. This specific model represents a standard right-angle header variant commonly used in modern electronic assemblies where traditional through-hole components are unsuitable.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 17-position count, 2.54mm pitch, and right-angle SMD form factor. Verify that alternative manufacturers provide identical tin-plated brass contacts and compatible insulation materials to ensure interchangeability without redesigning the PCB.
