350-80-163-00-024101

Headers, Male Pins Overview

The Preci-Dip 350-80-163-00-024101 is a vertical header connector featuring 63 positions with a 0.100-inch (2.54mm) pitch. Designed for through-hole mounting, it utilizes gold-plated contacts to ensure reliable signal transmission. The unit operates within a temperature range of -55°C to 125°C and supports up to 3A current at 150VDC. Constructed with PCT insulation and UL94 V-0 rated materials, this single-row component provides robust board-to-board connectivity in electronic assemblies.

Headers, Male Pins Feature Summary

• Vertical pin configuration for standard board stacking
• Gold contact plating for enhanced conductivity and corrosion resistance
• High-temperature resistant PCT insulation material
• Through-hole solder tail termination method

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Industrial control panel wiring
• Consumer electronics assembly
• Communication equipment interfaces

Headers, Male Pins Procurement Notes

Verify the exact position count and pitch compatibility against your PCB footprint before ordering. Confirm that the gold plating specification meets your environmental requirements. Ensure the through-hole solder tail length aligns with your board thickness constraints. Cross-reference the manufacturer part number to avoid confusion with similar series components.

Headers, Male Pins Selection Notes

Select this model when a high-density 63-position connection is required in a single row. Consider the vertical profile for space-constrained applications where height is not restricted. Evaluate the thermal stability requirements against the specified operating temperature range. Compare against alternative series if different contact materials or insulation properties are needed.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 350 series, which specializes in rectangular headers and male pins. The series offers various position counts and pitch options to suit diverse electronic design needs. Preci-Dip manufactures these connectors using Swiss precision engineering standards, focusing on reliability and durability for industrial and commercial applications.

Headers, Male Pins Replacement Considerations

Direct substitutes include other 63-position, 2.54mm pitch headers from compatible manufacturers. Verify mechanical dimensions and electrical ratings match exactly. Check for equivalent contact plating and insulation material specifications. Ensure the mounting style remains through-hole vertical.
