350-V3-121-00-106101

Headers, Male Pins Overview

The Preci-Dip 350-V3-121-00-106101 is a single-row board-to-board header connector from the 350 series. It features 12 positions with a 2.54mm (0.100 inch) pitch and utilizes surface-mount technology for PCB installation. The contacts are male pins made of brass, plated with gold on the mating interface and tin on the tail. Rated for 3A current and 150V DC, it operates within a temperature range of -55°C to 125°C. The housing is constructed from glass-filled polyester.

Headers, Male Pins Feature Summary

• Surface-mount design for automated assembly
• Gold-plated contact interface for reliable signal transmission
• Glass-filled polyester insulation for thermal stability

Headers, Male Pins Applications

• High-density electronic assemblies
• Industrial control systems
• Consumer electronics interconnects

Headers, Male Pins Procurement Notes

Verify the specific part number against official Preci-Dip documentation to confirm pin count and plating specifications. Ensure compatibility with surface-mount reflow processes. Check for RoHS compliance status if required by project standards. Confirm that the 12-position configuration matches the target PCB footprint requirements.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount header is required for board-to-board connections. The 350 series offers a balance of electrical performance and mechanical reliability. Consider the 2.54mm pitch for standard spacing needs and the gold plating for applications requiring corrosion resistance and stable contact impedance.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 350 series, which specializes in surface-mount headers. The series is designed for high-reliability applications where space constraints and automated manufacturing efficiency are priorities. The 350-V3 variant specifically denotes the surface-mount style with defined insulation height and contact length characteristics.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Preci-Dip 350 series headers with identical pin counts and mounting styles. Verify that any alternative maintains the same 2.54mm pitch, gold plating thickness, and UL94 V-0 flammability rating to ensure functional equivalence.
