3627453226330K is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists TE Connectivity Passive Product. Its product description is FIXED IND 33UH 270MA 1.2OHM SMD. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for 3627453226330K
- Description：FIXED IND 33UH 270MA 1.2OHM SMD
- Series：3627, Sigma Inductors
- Mfr：TE Connectivity Passive Product
- Package：Tape & Reel (TR),Cut Tape (CT)
- Type：Wirewound
- Material - Core：Ferrite
- Inductance：33 µH
- Tolerance：±10%
- Current Rating (Amps)：270 mA
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：1.2Ohm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：1 MHz
- Mounting Type：Surface Mount
- Package / Case：1812 (4532 Metric)
- Supplier Device Package：1812
- Size / Dimension：0.177" L x 0.126" W (4.50mm x 3.20mm)
- Height - Seated (Max)：0.118" (3.00mm)
- Features：-
Fixed Inductors datasheet and documents for 3627453226330K
Fixed Inductors Overview
The TE Connectivity Passive Product inductor, part number 3627453226330K, is an unshielded wirewound component designed for high-frequency communication applications. It features a nominal inductance of 33 µH with a maximum DC resistance of 1.2 Ohms and a rated current of 270 mA. The device utilizes an 1812 (4532 Metric) surface-mount package.
Fixed Inductors Feature Summary
- Unshielded wirewound construction suitable for specific RF environments
- Engineered for integration into high-frequency communication products
Fixed Inductors Applications
- High-frequency communication equipment
- RF signal processing circuits
- Telecommunications infrastructure components
Fixed Inductors Procurement Notes
Verify the exact manufacturer part number against official TE Connectivity documentation to ensure compatibility. Confirm that the 1812 package dimensions and electrical ratings align with the target circuit design requirements before finalizing procurement decisions.
Fixed Inductors Selection Notes
Select this component when designing for high-frequency communication systems requiring unshielded wirewound inductors. Ensure the 270 mA current rating and 1.2 Ohm DC resistance meet the specific power and impedance constraints of the application circuit.
Fixed Inductors Part Context
This component belongs to the TE Connectivity Passive Product portfolio, which includes resistors, capacitors, and sensors. These passive elements are engineered for reliability in automotive, industrial, and telecommunications sectors, supporting complex electronic system architectures.
Fixed Inductors Replacement Considerations
No public confirmed substitute part numbers are available in the provided source material. Verify cross-compatibility with alternative suppliers using independent technical specifications if sourcing changes are required.
