Edgeboard Connectors Overview

The EDAC Inc. 395-009-523-188 is a standard card edge connector featuring 9 positions with a single row of female contacts. It utilizes a 0.100 inch (2.54mm) pitch and accepts printed circuit boards with a nominal thickness of 0.062 inches (1.57mm). The connector employs gold-plated copper alloy contacts for reliable signal transmission. Designed for vertical panel mounting, it uses solder pin termination to secure the connection to the PCB. The housing is constructed from black thermoplastic polyester, providing structural integrity and insulation.

Edgeboard Connectors Feature Summary

• Accepts 0.062 inch nominal thickness PCBs
• Vertical panel mount configuration
• Gold-plated contact finish

Edgeboard Connectors Applications

• Industrial control systems
• Automotive electronics
• Telecommunications equipment

Edgeboard Connectors Procurement Notes

Verify the specific ordering suffix against official EDAC documentation to ensure correct contact plating and material specifications. Confirm that the required board thickness matches the 0.062-inch design limit. Check current distributor availability as supply status may vary by region. Ensure the selected variant meets all necessary environmental ratings for the intended operating temperature range.

Edgeboard Connectors Selection Notes

Select this component when a low-profile, single-row interface is required for thin circuit boards. The 9-position count suits applications with limited I/O requirements. Verify that the vertical mounting style aligns with the chassis layout. Consider the thermal properties of the polyester insulator for high-temperature environments. Ensure the solder pin termination method is compatible with the assembly process.

Edgeboard Connectors Part Context

This part belongs to the EDAC 395 series of standard card edge connectors. The series is characterized by a consistent 0.100-inch contact spacing and compatibility with 0.062-inch thick boards. Variations within the series typically differ by position count, row configuration, and mounting orientation. This specific model represents a compact, single-row solution within that standardized family.

Edgeboard Connectors Replacement Considerations

Cross-reference with other EDAC 395-series parts sharing identical pitch and board thickness. Verify mechanical dimensions and mounting hole patterns before substitution. Ensure electrical ratings match the original design requirements.
