395-010-558-503

Edgeboard Connectors Overview

The EDAC Inc. 395-010-558-503 is a standard card edge connector designed for single-sided PCB applications. It features 10 positions with a 0.100 inch (2.54mm) pitch and utilizes female contacts. The connector employs a double-row configuration with a right-angle mounting orientation, suitable for vertical board connections. Contact surfaces are gold-plated to ensure reliable signal transmission. The insulator is constructed from black thermoplastic polyester, providing durability across an operating temperature range of -40°C to +105°C.

Edgeboard Connectors Feature Summary

• Double-row female contact configuration for dual-edge card insertion
• Right-angle mounting design for vertical PCB integration
• Gold-plated contacts for enhanced conductivity and corrosion resistance
• Thermoplastic polyester insulator housing for thermal stability

Edgeboard Connectors Applications

• Single-sided printed circuit board interconnections
• Vertical mating with edge cards in industrial equipment
• Signal routing in control panels requiring right-angle access

Edgeboard Connectors Procurement Notes

Verify the specific suffix codes against manufacturer documentation to confirm exact physical dimensions and flange characteristics. Ensure compatibility with target PCB thickness specifications before procurement. Cross-reference RoHS compliance status with current regulatory requirements for the intended market. Confirm that the right-angle orientation aligns with mechanical assembly constraints.

Edgeboard Connectors Selection Notes

Select this component when a double-row, right-angle interface is required for single-sided boards. The 0.100-inch pitch accommodates standard trace spacing. Verify that the target application does not require single-row or straight-mount alternatives. Consider the thermal rating of the polyester insulator for high-temperature environments.

Edgeboard Connectors Part Context

This part belongs to the EDAC 395 series of standard card edge connectors. The series offers various position counts and row configurations. The 395-010 variant specifically addresses low-pin-count applications requiring robust vertical connectivity. It shares common material properties with other models in the family but differs in pin count and mounting geometry.

Edgeboard Connectors Replacement Considerations

Direct substitutes within the same series include parts with identical pitch and row counts but different pin numbers. Verify mechanical fit for any cross-series replacements. Ensure electrical ratings match the original design requirements.
