395-020-524-178 is listed in the Edgeboard Connectors range at ChipApex. The manufacturer field lists EDAC Inc.. Its product description is CONN EDGE SINGLE FML 20POS 0.100. Review the specifications below when checking this part for your BOM.
Edgeboard Connectors specifications for 395-020-524-178
- Description：CONN EDGE SINGLE FML 20POS 0.100
- Series：395
- Mfr：EDAC Inc.
- Package：Box
- Card Type：Non Specified - Single Edge
- Gender：Female
- Number of Positions/Bay/Row：20
- Number of Positions：20
- Card Thickness：0.054" ~ 0.070" (1.37mm ~ 1.78mm)
- Number of Rows：1
- Pitch：0.100" (2.54mm)
- Read Out：Single
- Features：Card Guides
- Mounting Type：Through Hole
- Termination：Solder
- Contact Material：Copper Alloy
- Contact Finish：Gold
- Contact Finish Thickness：10.0µin (0.25µm)
- Contact Type：Cantilever
- Color：Black
- Flange Feature：Flush Mount, Top Opening, Threaded Insert, 4-40
- Operating Temperature：-40°C ~ 105°C
Edgeboard Connectors datasheet and documents for 395-020-524-178
Edgeboard Connectors Overview
The EDAC Inc. 395-020-524-178 is a single-row card edge connector designed for through-hole mounting. It features 20 female positions with a 0.100 inch (2.54mm) pitch. The contacts are made of copper alloy with gold plating, and the insulator is black thermoplastic polyester. It accepts board thicknesses from 0.054 to 0.070 inches.
Edgeboard Connectors Feature Summary
- Single-sided female contact configuration for non-specified card edges
- Through-hole termination method using wire wrap style terminals
- Gold-plated copper alloy contacts for reliable signal transmission
- Thermoplastic polyester insulator housing with top-mount flange openings
Edgeboard Connectors Applications
- General purpose electronic circuit interconnections
- Industrial control system backplanes
- Consumer electronics module interfaces
Edgeboard Connectors Procurement Notes
Verify the specific ordering suffix matches the required terminal type and flange configuration. Confirm that the target PCB design accommodates the specified 0.100 inch pitch and single-row layout. Ensure compatibility with the intended card thickness range before finalizing procurement orders.
Edgeboard Connectors Selection Notes
Select this component when a single-row, 20-position interface is required. Consider the through-hole installation method and wire-wrap termination style. Verify that the gold contact plating meets the environmental durability requirements for the application environment.
Edgeboard Connectors Part Context
This part belongs to the EDAC 395 series of standard card edge connectors. The series offers various position counts and termination styles. This specific model provides a compact solution for vertical board-to-board or board-to-backplane connections in constrained spaces.
Edgeboard Connectors Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Cross-reference with other EDAC 395 series variants only if mechanical and electrical specifications match exactly.
