Headers, Male Pins Overview

The Mill-Max 399-10-164-10-009000 is a spring-loaded interconnect header designed for through-hole mounting. It features a right-angle configuration with 64 positions arranged in a single row. The connector utilizes a 0.100-inch (2.54mm) pitch to accommodate board-to-board applications. This component provides reliable performance in environments requiring uneven mating surfaces or floating height adjustments.

Headers, Male Pins Feature Summary

• Spring-loaded contact mechanism ensures consistent electrical connection despite surface irregularities
• Right-angle design facilitates compact vertical integration within assembly constraints
• Through-hole termination method provides robust mechanical stability on the printed circuit board

Headers, Male Pins Applications

• Board-to-board interconnections requiring flexible alignment
• Systems with uneven mating surfaces or floating height variations
• Harsh environment applications demanding high reliability and field-proven performance

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 64-position count and single-row configuration. Confirm the right-angle orientation aligns with the PCB layout requirements. Ensure the through-hole mounting style is compatible with the manufacturing process. Cross-reference the 0.100-inch pitch specification against mating connector dimensions to guarantee proper fit and electrical continuity.

Headers, Male Pins Selection Notes

Select this component when standard rigid headers cannot accommodate misalignment or height differences between boards. The spring-loaded feature is critical for maintaining contact integrity under vibration or thermal cycling conditions where fixed spacing may fail. Consider the right-angle form factor for space-constrained designs requiring vertical signal routing without additional cabling.

Headers, Male Pins Part Context

This component belongs to the Mill-Max spring-loaded interconnect series, which specializes in precision-machined contacts for demanding electronic applications. The manufacturer focuses on high-reliability solutions for industrial, defense, and data center sectors. These connectors are engineered to withstand harsh operating conditions while providing low contact resistance and long cycle life compared to traditional fixed headers.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers: None identified.
