3EK7M

Overview

The TE Connectivity Corcom Filters 3EK7M is a single-phase EMC/EMI line filter rated for 250VAC and 3A at 50/60Hz. It features a single-stage configuration with IEC 320-C14 connector style and quick connect termination. Designed for chassis mounting, it operates within a temperature range of -10°C to 40°C.

Feature Summary

• Single-phase EMI/RFI suppression for power line filtering
• IEC 320-C14 input connector with quick connect terminals
• Chassis mount installation design

Applications

• General-purpose electronic equipment requiring EMI suppression
• Industrial control systems
• Medical devices

Procurement Notes

Verify the specific series designation (SK) and certification requirements (CSA, UR, VDE) against your system's regulatory needs. Confirm that the chassis mounting style and terminal type match your assembly process. Ensure the operating temperature range meets environmental specifications.

Selection Notes

Select this component when a single-stage filter is sufficient for noise reduction in 250VAC, 3A circuits. The IEC 320-C14 interface simplifies integration with standard power cords. Consider the chassis mount form factor if panel space is limited or direct board mounting is not feasible.

Part Context

Part of the TE Connectivity Corcom SK series, designed for general-purpose EMI/RFI filtering. It provides essential noise suppression for sensitive electronics while maintaining compliance with international safety standards through CSA, UR, and VDE certifications.

Replacement Considerations

FN9246-3-06 by TE Connectivity Schaffner is listed as a similar substitute part number.
