3FBH3=F8590

Overview

The TE Connectivity Corcom Filters model 3FBH3=F8590 is a single-phase EMC/EMI line filter designed for industrial applications. It supports a rated current of 3 A and operates at 480 VAC with a frequency range of 50 to 60 Hz. The unit utilizes a single-stage filtering configuration and features wire lead termination for circuit integration.

Feature Summary

• Provides electromagnetic interference suppression through single-stage filtering
• Engineered for high-voltage AC power line protection
• Utilizes direct wire lead connections for system integration

Applications

• Industrial machinery power input stages
• Commercial equipment requiring EMI mitigation
• General-purpose AC power line filtering

Procurement Notes

Verify the specific voltage rating and terminal configuration against your system requirements before procurement. Confirm that the wire lead termination style matches your assembly process. Ensure the component meets all necessary regional safety certifications for your target market deployment.

Selection Notes

Select this component when a single-phase, 3 A rated filter is required for 480 VAC systems. Consider the single-stage topology for basic noise reduction needs. Verify physical dimensions and mounting constraints if chassis integration is planned.

Part Context

This part belongs to the TE Connectivity Corcom Filters series, which specializes in power entry modules and line filters. The product line focuses on providing reliable EMI/RFI suppression solutions for various commercial and industrial electronic equipment applications globally.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
