Product Detailed Parameters
- Description：LINE FILTER 250VAC 3A CHASS MNT
- Series：B
- Mfr：TE Connectivity Corcom Filters
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：3:00 AM
- Frequency - Operating：50/60Hz
- Applications：General Purpose
- Approval Agency：CSA, UR, VDE
- Operating Temperature：-10°C ~ 40°C
- Mounting Type：Chassis Mount
- Termination Style：Wire Leads
- Inductance：1.76mH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The TE Connectivity Corcom Filters 3VB3 is a single-phase EMC/EMI line filter designed to reduce electrical noise and interference on AC power lines. It is rated for 3 amps at 250VAC, with a maximum leakage current of 700µA. The component functions as a compact RFI power line filter intended to clean up noisy power lines in commercial applications.
Feature Summary
- Single-phase EMC/EMI filtering capability
- Compact form factor for space-constrained installations
- Designed to reduce electrical noise and interference
Applications
- Commercial electronic equipment requiring EMI suppression
- AC power line noise reduction
- RFI mitigation in sensitive circuits
Procurement Notes
Verify the specific datasheet version and compliance status (RoHS/REACH) directly with TE Connectivity or authorized distributors before procurement. Confirm that the 700µA leakage current specification meets your system safety requirements. Ensure the 3A rating aligns with your load demands. Check for any recent product change notices (PCN) regarding manufacturing locations or material composition updates.
Selection Notes
Select this component when a single-phase solution is required for moderate current loads up to 3A at 250VAC. Consider the low leakage current specification if personnel safety or strict regulatory limits are critical. Evaluate the physical dimensions against available chassis or panel space. Compare against other Corcom series filters if higher current ratings or different mounting styles are needed.
Part Context
This part belongs to the TE Connectivity Corcom Filters family, which specializes in power line filters and connectors. The 3VB3 specifically addresses EMI/RFI suppression needs within the broader portfolio of industrial and commercial interconnect solutions provided by the manufacturer.
Replacement Considerations
Consult official TE Connectivity substitution guides for verified alternatives. Generic cross-references may not match the specific leakage current or filtering characteristics. Verify pinout and mounting compatibility if replacing in an existing design.
