406C35S14M31818

$0.52

Description：CRYSTAL 14.31818MHZ SERIES SMD
Series：406
Mfr：CTS-Frequency Controls
Package：Tape & Reel (TR)

SKU:7295eda382bc Category: Crystals Brand: CTS-Frequency Controls

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

406C35S14M31818 is listed in the Crystals range at ChipApex. The manufacturer field lists CTS-Frequency Controls. Its product description is CRYSTAL 14.31818MHZ SERIES SMD. Review the specifications below when checking this part for your BOM.

Crystals specifications for 406C35S14M31818

Description：CRYSTAL 14.31818MHZ SERIES SMD
Series：406
Mfr：CTS-Frequency Controls
Package：Tape & Reel (TR)
Type：MHz Crystal
Frequency：14.31818 MHz
Frequency Stability：±50ppm
Frequency Tolerance：±30ppm
Load Capacitance：Series
ESR (Equivalent Series Resistance)：60 Ohms
Operating Mode：Fundamental
Operating Temperature：-20°C ~ 70°C
Ratings：-
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.236" L x 0.138" W (6.00mm x 3.50mm)
Height - Seated (Max)：0.047" (1.20mm)

Crystals datasheet and documents for 406C35S14M31818

406C35S14M31818

Crystals Overview

The CTS-Frequency Controls 406C35S14M31818 is a surface-mount quartz crystal resonator operating at a fundamental frequency of 14.31818 MHz. It features a frequency tolerance of ±30 ppm and a frequency stability of ±50 ppm. The component utilizes a 4-SMD, no-lead package with dimensions of 6.00 mm in length, 3.50 mm in width, and 1.20 mm in height. Designed for operation within a temperature range of -20°C to +70°C, it exhibits an equivalent series resistance (ESR) of 60 Ohms and requires a load capacitance specified by the Series designation. The device supports a maximum drive level of 100 uW.

Crystals Feature Summary

Fundamental mode quartz crystal construction
Surface mount SMD package configuration
Industrial temperature range capability

Crystals Applications

Digital signal processing clock sources
Microcontroller system timing
Communication interface synchronization

Crystals Procurement Notes

Verify the specific suffix code against the manufacturer datasheet to confirm exact electrical parameters and packaging options. Ensure the ordering suffix matches the required load capacitance and tolerance specifications for the target application circuit design.

Crystals Selection Notes

Select this component when a standard 14.31818 MHz reference frequency is required for digital logic circuits. Consider the physical footprint constraints and thermal environment limits during integration into the printed circuit board layout.

Crystals Part Context

This part belongs to the 406 Series of surface-mount crystals from CTS-Frequency Controls. The series provides various frequency options in standardized packages suitable for high-volume consumer and industrial electronics manufacturing processes.
