4071-F04TDT-P

$0.81

Description：2.54mm wafer, SMD, 4pin,T&R,pa
Series：4071
Mfr：Oupiin
Package：Tape & Reel (TR)

SKU:eda063e04f27 Category: Headers, Male Pins Brand: Oupiin

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：2.54mm wafer, SMD, 4pin,T&R,pa
Series：4071
Mfr：Oupiin
Package：Tape & Reel (TR)
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：4
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Friction Lock
Contact Length - Mating：0.290" (7.37mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.125" (3.18mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：80.0µin (2.03µm)
Contact Finish - Post：-
Contact Material：Brass
Insulation Material：Liquid Crystal Polymer (LCP)
Features：Pick and Place
Operating Temperature：-25°C ~ 85°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：250VAC/DC

Download product information

4071-F04TDT-P

Overview

The Oupiin 4071-F04TDT-P is a surface mount header connector featuring four positions with a 2.54mm (0.100-inch) pin spacing. It utilizes tin-plated terminals compatible with 22AWG to 28AWG wire gauges. The component supports AC/DC voltage ratings of 250V and current ratings of 3A, with a dielectric withstand voltage of AC 1000V for one minute. Operating temperatures range from -25°C to +85°C. The unit is supplied in tape and reel packaging.

Feature Summary

Surface mount design for automated assembly efficiency
Secure locking mechanism for reliable connection integrity
Tin-plated contacts ensuring corrosion resistance

Applications

Communication equipment interconnections
Computer peripheral connections
Industrial manufacturing control systems

Procurement Notes

Verify the specific suffix 'P' indicates tape and reel packaging configuration as documented. Confirm RoHS compliance status through official manufacturer declarations. Ensure compatibility with standard SMT reflow profiles. Cross-reference part numbers against the latest Oupiin catalog to avoid obsolete variants.

Selection Notes

Select this component for applications requiring low-profile surface mount headers. The 2.54mm pitch suits general-purpose board-to-wire connections. Consider the 3A current rating for power distribution needs. Verify housing material requirements against environmental operating conditions.

Part Context

This part belongs to the Oupiin 4071 Series, which includes various wafer and housing configurations. The series features robust contacts and secure locking mechanisms. Other variants include different pin counts and mounting orientations within the same 2.54mm family architecture.
