40IMX15-24-24-8ZG

40IMX15-24-24-8ZG is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Bel Power Solutions. Its product description is DC DC CONVERTER 24V 24V 15W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for 40IMX15-24-24-8ZG

• Description：DC DC CONVERTER 24V 24V 15W
• Series：Melcher IMX15 (15W)
• Mfr：Bel Power Solutions
• Package：Bulk
• Type：Isolated Module, Conformal Coated
• Number of Outputs：2
• Voltage - Input (Min)：16.8V
• Voltage - Input (Max)：75V
• Voltage - Output 1：24V
• Voltage - Output 2：24V
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：350mA, 350mA
• Power (Watts)：15 W
• Voltage - Isolation：2.1 kV
• Applications：-
• Features：OCP, OTP, OVP, SCP, UVLO
• Operating Temperature：-40°C ~ 85°C
• Efficiency：86%
• Mounting Type：Through Hole
• Package / Case：17-DIP Module, 9 Leads
• Size / Dimension：1.80" L x 1.52" W x 0.35" H (45.7mm x 38.8mm x 8.9mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for 40IMX15-24-24-8ZG
