4172-02TSB

Overview

The Oupiin 4172-02TSB is a 2.0mm pitch wire-to-board header connector designed for PCB mounting. This specific variant features a straight, shrouded receptacle configuration with two contacts arranged in a single row. The component utilizes pin-type terminals and includes a PC tail with retention mechanisms to ensure secure board attachment. A locking ramp structure is integrated into the housing design to prevent accidental disengagement during mating cycles. The part is constructed from natural-colored plastic materials and complies with RoHS environmental standards for restricted hazardous substances.

Feature Summary

• Shrouded header design prevents misalignment during insertion
• Integrated locking ramp secures mating connections
• PC tail with retention mechanism ensures stable PCB mounting

Applications

• Wire-to-board interconnections in consumer electronics
• Internal wiring harnesses in industrial control systems
• Signal transmission in telecommunications equipment

Procurement Notes

Verify that the required contact count matches the two-pin specification of this model. Confirm the straight orientation aligns with your PCB layout requirements. Ensure the natural color variant meets your assembly visibility needs. Check that the 2.0mm pitch is compatible with your mating cable or housing components. Validate RoHS compliance documentation if required by your supply chain regulations.

Selection Notes

Choose this model when a low-profile, two-position connection is needed. The shrouded design offers protection against cross-pin shorting. Consider the locking feature for applications requiring vibration resistance. The straight orientation simplifies routing compared to right-angle alternatives. Verify terminal compatibility with standard 22AWG to 28AWG wires if using mating terminals.

Part Context

This component belongs to the 4172 series of 2.0mm pitch connectors manufactured by Oupiin. The series provides various configurations including different pin counts and orientations. It serves as a standard interconnect solution for general-purpose electronic assemblies where reliable signal and power transfer is required between flexible cables and rigid printed circuit boards.

Replacement Considerations

No public substitute part numbers are documented for this specific component.
