4306-004LF

Overview

The 4306-004LF is a feedthrough capacitor manufactured by Tusonix, a subsidiary of CTS Electronic Components. It features a capacitance of 5000 pF with a rated voltage of 100V and a maximum current rating of 5 A. The component utilizes an axial, press-fit package configuration. Its physical dimensions include a length of approximately 8.00 mm and a width of 2.29 mm, with a maximum height of 2.42 mm. The device operates within a temperature range of -55°C to +125°C and offers a tolerance of 0% to +100%. It is designed for EMI suppression applications.

Feature Summary

• Provides electromagnetic interference filtering through high-capacitance feedthrough design
• Supports axial press-fit mounting for secure mechanical integration
• Operates reliably across extended industrial temperature ranges

Applications

• EMI suppression in electronic equipment chassis
• Power line filtering for sensitive instrumentation
• Signal integrity protection in industrial control systems

Procurement Notes

Verify the specific manufacturer part number against official CTS/Tusonix documentation to confirm active status and exact specifications. Ensure that the axial press-fit mounting style aligns with the target PCB or panel layout requirements. Confirm compliance with relevant environmental standards such as RoHS before finalizing procurement decisions.

Selection Notes

Select this component when a high capacitance value of 5000 pF is required at 100V ratings. The axial form factor suits applications where panel penetration or bulkhead mounting is necessary. Consider the 5 A current limit and thermal operating range to ensure compatibility with the system's electrical and environmental conditions.

Part Context

This component belongs to the 4306 series of EMI feedthrough filters produced by Tusonix. The series is characterized by robust construction suitable for harsh environments. The 4306-004LF specifically addresses scenarios requiring significant capacitance for low-frequency noise attenuation while maintaining structural integrity through its press-fit interface.

Replacement Considerations

Consult official CTS/Tusonix substitution guides for verified alternatives. Cross-reference parameters such as capacitance, voltage rating, and mounting style when evaluating potential substitutes to ensure functional equivalence.
