435-10-220-00-160000

Headers, Male Pins Overview

The Mill-Max 435-10-220-00-160000 is a vertical header connector designed for through-hole mounting. It features 20 positions with a 0.100-inch (2.54mm) contact spacing. The connector utilizes male pin contacts with a round shape and tin plating. Key dimensions include an insulation height of 0.110 inches, a mating contact length of 0.166 inches, and a total contact length of 0.477 inches.

Headers, Male Pins Feature Summary

• Vertical orientation for standard board-to-board or device connections
• Through-hole termination method for secure PCB attachment
• Push-pull fastening type for stable mechanical retention

Headers, Male Pins Applications

• General electronic interconnects
• Board-to-board connections
• Device interface modules

Headers, Male Pins Procurement Notes

Verify the specific manufacturer part number against official Mill-Max documentation to ensure compatibility with design requirements. Confirm that the through-hole footprint and pin count match the target printed circuit board layout. Check for any updated environmental compliance certifications if required by the end product specifications.

Headers, Male Pins Selection Notes

Select this component when a low-profile vertical header with 20 pins and 2.54mm spacing is required. Ensure the mating connector accommodates the specified 0.166-inch contact length. Consider the push-pull fastening mechanism for assembly constraints and verify that the tin-plated contacts meet the corrosion resistance needs of the operating environment.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 435 series of rectangular connectors. The series is characterized by low-profile designs suitable for space-constrained applications. Mill-Max Manufacturing Corp. specializes in high-reliability precision-machined interconnect components, providing standardized solutions for various industrial and commercial electronics markets.

Headers, Male Pins Replacement Considerations

Consult official Mill-Max catalogs for direct substitutes within the 435 series. Verify that alternative parts maintain identical pin counts, spacing, and mounting styles. Cross-reference datasheets to confirm mechanical and electrical compatibility before substitution.
