435F122XXCDT

Crystals Overview

The CTS-Frequency Controls 435F122XXCDT is a MHz crystal resonator designed for surface mount applications. It features a 5.0mm x 3.2mm 2-pad SMD package with dimensions of 0.197" L x 0.126" W. The component offers a frequency tolerance of ±15ppm and stability of ±30ppm. It operates within a temperature range of -40°C to +85°C and utilizes a standard lead-free/RoHS compliant construction.

Crystals Feature Summary

• Compact 2-pad surface mount design optimizing PCB space
• Wide operating temperature range suitable for industrial environments
• High frequency stability ensuring reliable clock signals

Crystals Applications

• Industrial control systems requiring stable timing references
• Consumer electronics utilizing compact form factors
• Telecommunications equipment needing precise frequency generation

Crystals Procurement Notes

Verify the specific suffix code (e.g., XX) against official CTS documentation to confirm exact electrical parameters such as load capacitance and ESR, as generic part numbers may represent multiple variants. Ensure compatibility with reflow soldering profiles specified in the datasheet. Confirm RoHS compliance status for regulatory adherence in target markets.

Crystals Selection Notes

Select this component when a 5.0mm x 3.2mm footprint is required with high stability. Compare against similar series like 435F1221XIET for pinout and parameter differences. Consider thermal performance and mounting constraints during layout design. Validate that the ±15ppm tolerance meets system requirements.

Crystals Part Context

This part belongs to the CTS 435 Series of MHz crystals, characterized by small outline packages. It complements other SMD crystals in the portfolio offering various frequencies and tolerances. The series targets applications demanding reliability in harsh environments while maintaining low profile heights.

Crystals Replacement Considerations

Direct substitutes include 435F1221XIET and 435F122XXCDT variants with matching footprints. Verify equivalent electrical characteristics before substitution.
