Headers, Receptacles, Female Sockets Overview

The Molex 44812-0024 is a KK 254 series rectangular connector receptacle designed for low-profile applications. It features six positions with a 2.54 mm (0.100 inch) pitch and utilizes a single-row configuration. The component employs through-hole termination for secure PCB mounting. Contact surfaces are plated with 0.38 µm of gold to ensure reliable electrical performance. This straight pin header is engineered for compact electronic assemblies requiring robust connectivity.

Headers, Receptacles, Female Sockets Feature Summary

• Low-profile design suitable for space-constrained enclosures
• Gold-plated contacts for enhanced conductivity and corrosion resistance
• Single-row straight pin configuration for standard board mounting

Headers, Receptacles, Female Sockets Applications

• Compact consumer electronics assemblies
• Industrial control system interconnects
• Communication equipment circuit boards

Headers, Receptacles, Female Sockets Procurement Notes

Verify the part number suffix against official Molex documentation to confirm specific contact plating thickness and material composition. Ensure that the selected variant matches the required through-hole termination style and housing color specifications for your assembly. Cross-reference the manufacturer's latest datasheet to confirm RoHS compliance status and availability constraints before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, six-position connector is required for through-hole PCB integration. The 2.54 mm pitch ensures compatibility with standard wire harnesses and mating headers within the KK 254 family. Consider the straight pin orientation for vertical board mounting and verify that the 0.38 µm gold plating meets the environmental durability requirements of the target application environment.

Headers, Receptacles, Female Sockets Part Context

This receptacle belongs to the Molex KK 254 product line, which is widely utilized in various electronic industries for its reliability and compact form factor. The series supports both surface mount and through-hole technologies, offering flexibility in design. As a six-position unit, it provides a balanced solution for moderate I/O requirements in dense circuit layouts without compromising signal integrity or mechanical stability.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other Molex KK 254 series receptacles with identical six-position counts and 2.54 mm pitch. Verify that alternative parts maintain the same through-hole termination style and straight pin orientation. Ensure mating headers share the corresponding housing dimensions and contact spacing to guarantee proper mechanical fit and electrical continuity in the final assembly.
