450-10-256-00-001101

Headers, Male Pins Overview

The Preci-Dip 450-10-256-00-001101 is a vertical pin header connector featuring 56 positions arranged in two rows with a 0.100-inch (2.54mm) pitch. Designed for board-to-board applications, it utilizes through-hole termination and push-pull fastening mechanisms. The contacts are made of brass with a gold plating thickness of 10.0µin (0.25µm). Rated for 3A current and 150VDC, the unit operates within a temperature range of -55°C to 125°C. The housing is constructed from black glass-filled polyester meeting UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Vertical pin header configuration designed for secure board-to-board interconnection
• Push-pull fastening mechanism ensures reliable mating stability without additional hardware
• Gold-plated brass contacts provide durable electrical conductivity and corrosion resistance
• Glass-filled polyester insulation offers high thermal stability and UL94 V-0 fire rating

Headers, Male Pins Applications

• High-density electronic assembly requiring robust vertical interconnects
• Industrial control systems operating within extreme temperature environments
• Consumer electronics utilizing standard 2.54mm spacing architectures
• Automotive circuit boards demanding reliable signal transmission under vibration

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required 56-position count and dual-row layout before integration. Confirm that the 2.54mm pitch aligns with the target PCB footprint design. Ensure the operating environment stays within the specified -55°C to 125°C thermal limits. Check that the 3A current rating satisfies the application's power requirements. Validate compatibility with the intended mating connector system.

Headers, Male Pins Selection Notes

Choose this component when a vertical orientation and push-pull retention are necessary for the assembly process. Select this model if the application requires a 2.54mm pitch with a high contact density of 56 pins. Consider this part for environments where UL94 V-0 rated insulation is mandatory. Opt for this connector if through-hole mounting is preferred over surface mount alternatives.

Headers, Male Pins Part Context

This connector belongs to the Preci-Dip 450 series, which specializes in vertical pin headers. The series is characterized by its use of push-pull fasteners and standard 2.54mm spacing. It serves as a critical interconnect solution for rigid board-to-board connections in various industrial and commercial sectors.

Headers, Male Pins FAQ

What is the maximum current rating for this connector?

The connector is rated for a maximum current of 3 Amperes.

Does this connector include a protective shroud?

No, this specific model is supplied without a shroud or cover.

What material is used for the insulating housing?

The housing is made of black glass-filled polyester with a UL94 V-0 flammability rating.
