450-V3-236-00-006101

$5.04

Description：CONN HEADER VERT 36POS 2.54MM
Series：450
Mfr：Preci-Dip
Package：Bulk

SKU:9c78789858eb Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CONN HEADER VERT 36POS 2.54MM
Series：450
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：36
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.141" (3.60mm)
Contact Length - Post：0.114" (2.90mm)
Overall Contact Length：0.394" (10.00mm)
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：29.5µin (0.75µm)
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Download product information

450-V3-236-00-006101

Overview

The Preci-Dip 450-V3-236-00-006101 is a 36-position dual-row header connector designed for through-hole mounting. It features a 2.54mm (0.100 inch) mating pitch and a 2.54mm row spacing. The unit utilizes tin-plated contacts with brass terminals, rated for 3A current and 150VDC voltage. Operating temperature ranges from -55°C to 125°C, and the housing is constructed from glass-filled PCT material.

Feature Summary

Dual-row configuration providing high-density interconnect capability
Through-hole termination method for secure PCB attachment
Tin-plated contact finish ensuring reliable conductivity

Applications

General-purpose board-to-board interconnections
Industrial control system signal routing
Consumer electronics internal wiring harnesses

Procurement Notes

Verify that the specific suffix 'V3' matches your design requirements, as it may indicate distinct mechanical or environmental specifications compared to standard series variants. Confirm the through-hole orientation and pin count align with your PCB footprint before finalizing procurement orders.

Selection Notes

Select this component when a dual-row arrangement is necessary within a 2.54mm grid constraint. Ensure the 3A current rating meets circuit demands and verify that the 150VDC insulation level is sufficient for the application environment.

Part Context

This part belongs to the Preci-Dip 450 series of headers. The series typically offers various row counts and termination styles, including surface mount options, allowing designers to choose appropriate configurations for different assembly processes and space limitations.

Replacement Considerations

Cross-reference with model 450-80-236-00-006101 for potential mechanical compatibility, though termination style differences must be evaluated carefully.
