451-80-244-00-005101

$6.02

Description：CONN HEADER VERT 44POS 2.54MM
Series：451
Mfr：Preci-Dip
Package：Bulk

SKU:04cda149ac22 Category: Headers, Male Pins Brand: Preci-Dip

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

451-80-244-00-005101 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Preci-Dip. Its product description is CONN HEADER VERT 44POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 451-80-244-00-005101

Description：CONN HEADER VERT 44POS 2.54MM
Series：451
Mfr：Preci-Dip
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：44
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.118" (3.00mm)
Contact Length - Post：0.126" (3.20mm)
Overall Contact Length：0.846" (21.50mm)
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：-
Contact Finish - Post：Tin
Contact Material：Brass
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：150VDC

Headers, Male Pins datasheet and documents for 451-80-244-00-005101

451-80-244-00-005101

Headers, Male Pins Overview

The Preci-Dip 451-80-244-00-005101 is a vertical board-to-board header connector from the 451 series. It features 44 positions with a 0.100" (2.54mm) pitch across two rows. Designed for through-hole mounting, it utilizes gold-plated brass contacts and PCT insulation rated UL94 V-0. The component supports a maximum current of 3A at 150VDC and operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

Dual-row configuration providing high-density interconnect capability
Gold-plated contacts ensure reliable signal transmission
Thermoplastic insulation offers flame resistance and thermal stability

Headers, Male Pins Applications

High-density circuit board interconnections
Industrial control system backplanes
Telecommunications equipment interfaces

Headers, Male Pins Procurement Notes

Verify the specific contact plating thickness and material composition against the official datasheet before procurement. Confirm that the two-row header geometry matches the target PCB footprint requirements. Ensure the operating environment temperature remains within the specified -55°C to 125°C range for optimal performance and longevity.

Headers, Male Pins Selection Notes

Select this model when a compact, dual-row solution is required for board-to-board connections. The 2.54mm pitch ensures compatibility with standard industry components. Consider the 3A current rating and 150VDC voltage limit to ensure electrical safety margins are met for the intended application load.

Headers, Male Pins Part Context

This component belongs to the Preci-Dip 451 series of rectangular connectors. The series is characterized by its vertical header design and through-hole termination method. It serves as a male pin connector counterpart to matching female socket housings, facilitating secure mechanical and electrical connections between stacked or adjacent printed circuit boards.
