4700-009MLF

Overview

The 4700-009MLF is a surface-mount EMI/RFI feedthrough capacitor manufactured by Tusonix, a subsidiary of CTS Electronic Components. This component belongs to the 4700 series and features a pill, square package configuration with dimensions of 0.315 inches in length and 0.090 inches in width (8.00mm x 2.29mm). It provides a capacitance value of 470 pF with a rated voltage of 100V. The device is designed for high-frequency noise suppression applications.

Feature Summary

• Surface mount construction for automated assembly
• Pill, square package format
• EMI/RFI filtering capability

Applications

• General purpose electronic circuits

Procurement Notes

Verify the specific RoHS compliance status and lead times directly with authorized distributors or the manufacturer, as availability may vary. Confirm that the surface mount package dimensions align with your PCB footprint requirements before finalizing procurement decisions.

Selection Notes

Select this component when a compact surface-mount solution is required for low-capacitance filtering at 100V. Ensure the 470 pF value meets the circuit's attenuation needs and that the 8.00mm x 2.29mm footprint fits the designated board space.

Part Context

This part is part of the Tusonix 4700 series of feedthrough capacitors. These components are engineered to provide effective electromagnetic interference suppression in compact form factors suitable for modern surface-mount technology assemblies.

FAQ

What is the package type of the 4700-009MLF?

The 4700-009MLF utilizes a Pill, Square package type.

What is the rated voltage for this capacitor?

The rated voltage for the 4700-009MLF is 100V.
